Attitude Heading Reference system (AHRS) using an IMU sensor (3 axis gyro scope, 2 axis acceleration)
High performance stabilization in rough weathers
Honest 3 axis system – Stabilized azimuth and elevation with a skew unit Stabilized skew system guarantees perfect searching and tracking
Automatic skew control Antenna control unit displays heading value without gyro connection using AHRS derived from inverse kinematics technology
Ready for gyro compass connection for faster and more stable satellite
Tracking 6 sec of unwrap time
Compatible for DVB-S2 provides over 80 satellites parameters
DiSEqC 1.2 function available (automatic satellite switching using receiver up to 4 satellites)
Sleep mode activated by a long stay in a location and a signal loss (auto recovery)
DSP(Digital Signal Processor) control technology
High gain reflector
Built in GPS
| Dish Diameter | :61cm (24”) |
| Antenna Dimension | :69cm(H) x 67cm(D) |
| Antenna Weight | :18kg |
| Radome Material | :Plastic |
| Frequency | :10.75 ~ 12.75GHz |
| Minimum EIRP | :48dBW |
| Operating Platform 3 | :Axis (Stabilized Azimuth, Elevation and Skew angle) |
| LNB | :Quad / Quattro LNB (optional) |
| Skew Control | :Automatic (±130°) |
| Elevation Angle | :-10° ~ + 85° |
| Azimuth Angle | :690° |
| Cross Angle | :±35° |
| Ship Motion Roll | : ±25° at 8 sec periods |
| Ship Motion Pitch | : ±15° at 6 sec periods |
| Ship Motion Yaw | : ±25° at 8 sec periods |
| Ship’s Heading | :With or Without NMEA Compass |
| Pointing Accuracy | :0.2° RMS |
| Turning Rate | :Up to 50°/sec |
| GPS | :Built-In GPS |
| DiSEqC | :DiSEqC 1.2 |
| Temperature | :-20°C to +55°C |
| Humidity | :Up to 100% @ 40°C |
| Antenna Input Power | :24Vdc, 2.5A |
| ACU Size | :290 x 160 x 50mm |
| External I/O | :Mini-USB |
| Gyro Interface | :NMEA 0183 |
| Output Power | :24Vdc, 2.5A |
